Sample Concentrator
Product Details
The WSC100-2 Sample Concentrator features advanced microprocessor control combined with PID fuzzy logic technology, ensuring precise and stable temperature regulation. Unlike traditional water bath systems, it uses high-purity aluminum as the heat-conducting medium, significantly improving thermal uniformity and efficiency. Test tubes are securely held in an aluminum block, allowing simultaneous nitrogen blowdown for high-throughput sample concentration.
Features:
✔ Wide temperature control range with high precision
✔ Accommodates multiple samples simultaneously, enhancing throughput
✔ Quick-change aluminum blocks for flexible applications and easy cleaning
✔ Automatic fault detection and audible/visual alarms
✔ Built-in over-temperature protection for operational safety
✔ User-calibrated temperature deviation correction
Applications:
Residue Analysis: Pesticide residues in vegetables, fruits, grains, and plant tissues
Environmental Testing: Drinking water, surface water, groundwater, and wastewater analysis
Biological Research: Hormone detection, sample preparation for LC/GC-MS
Food & Beverage Testing: Milk, wine, beer, and other liquid foods
Pharmaceuticals: Sample concentration in TCM, drug discovery, and quality screening
Parameters:
Model | WSC100-2 |
Temp range | RT.+5°C -160°C |
Temp accuracy | ±0.5℃(@40℃) |
Temp accuracy | ±1℃(@120℃) |
Temp uniformity | ±0.5℃ |
Display accuracy | 0.1℃ |
Time range | 1min-99h59min/∞ |
Heating time | ≤15min(from 25℃ to 160℃) |
Needle length | 150mm |
Nitrogen flow rate | 15L/min |
Nitrogen pressure | 0.02Mpa (Gas needle≤16pcs) 0.05Mpa (Gas needle＞16pcs) |
Block quantity | 2 |
Max power | 500W |
Voltage | AC220V or AC110V, 50/60Hz |
Dimension(mm) | 260*220*450 |
Weight(kg) | 7.5 |
Optional Blocks:
Type | Description | Type | Description |
MD03 | 24*10mm | MD09 | 12*20mm |
MD04 | 24*12mm | MD10 | 8*26mm |
MD05 | 24*13mm | MD11 | 4*28mm |
MD06 | 16*15mm | MD12 | 3*40mm |
MD07 | 16*16mm | MD15 | 24*1.5mL (centrifuge tube) |
MD08 | 12*19mm | MD16 | 24*2.0mL (centrifuge tube) |
