The ultra centrifugal mill is widely applicable for processing a broad range of sample types, including soft, medium-hard, brittle, tough, and fibrous materials. Its high rotational speed enables samples to be ground in an extremely short time, achieving an "in-and-out" grinding process. The instrument features an anti-splash funnel design to ensure samples enter without escaping. The plug-and-play rotor and sieve ring design make cleaning more convenient, and the sample collection tray allows for easy removal of processed samples. With its efficient grinding technology and a wide range of accessories, the mill is adaptable to various sample preparation needs and types.

Principle

The sample is introduced through the funnel, and as it descends, it encounters a formidable impact force generated by the interaction with the rapidly rotating blades under the influence of high-speed centrifugal force, thereby undergoing initial preprocessing. Subsequently, the sample is subjected to further shearing, compression, and friction between the rotating blades and the stationary ring sieve. Particles with dimensions smaller than the sieve's apertures pass through to enter a circular collection tray, thus completing the comminution of the sample. This two-stage grinding principle yields a gentle yet highly efficient pulverization outcome. Due to the high efficiency of the grinding process, the residence time of the sample within the grinding chamber is significantly reduced, thereby mitigating any potential alterations to the sample's intrinsic properties.

Application

• Rubber, tobacco, corn, electronic components, minerals, soil, seeds, coatings, textiles, polymers, collagen, feed,pharmaceuticals, cereals, spices, chemical products, coffee beans, dried fruits and vegetables, waste materials, wood, plant raw materials, etc.

• For Thermally Sensitive Samples:The rapidly rotating blades ensure swift grinding, minimizing the thermal impact on the samples.

• For Difficult-to-Grinｄ Samples:Liquid nitrogen can be added prior to grinding to embrittle the samples, achieving the fineness required for analysis.

Product Advantages

The advantages of the operating principle are as follows:

• Immediate input and output

• Especially suitable for grinding soft, elastic, and fibrous samples

• Guarantees the required fineness of the output sample

The advantages of the accessories are as follows:

• Blades of various specifications and materials

• Sieve rings with different aperture sizes and materials

• Collection trays made of different materials

The advantages of the parameters are as follows:

• Adjustable speed from 0 to 20,000 rpm (customizable)

• Controllable output particle size

• Flexible processing capacity, suitable for both small and large quantities

Three types of blades are available:

• 6-tooth blade: Ideal for coarse, large, and fibrous samples

• 12-tooth blade: Suitable for general-purpose samples

• 24-tooth blade: Designed for fine and delicate samples

The advantages of the detailed design include:

• Overload indicator display

• Plug-and-play design for blades and sieve rings

• Anti-splash funnel

• Safety lock mechanism

Multiple sieve rings are available:

• The final output fineness can be tailored to meet

• Experimental requirements by selecting the

• Appropriate sieve ring aperture size.

Specifications
